Q-SYS NM-T1 Tabletop Mic

Designed for collaborative spaces, the Q-SYS NM-T1 Tabletop Mic stands out with advanced beamforming technology, which ensures optimal clarity and separation for every voice in the room. With four software-configurable zones (offering up to 360° coverage) you can enjoy flexible seating arrangements, reduced echo, and enhanced audio clarity.

Get an instant quote
tabletop
q dn qsys nm hero
q dn qsys nm hero top
q dn qsys nm hero bottom
q dn qsys nm hero top colors

An advanced touchless microphone.

The NM-T1 microphone features touchless mute capability via a proximity motion sensor, allowing users to mute or unmute with a simple hand wave for added convenience and hygiene in shared spaces. It also includes onboard call controls and a programmable user button customisable with Q-SYS Designer Software.

Fully manageable via Q-SYS Designer Software and Q-SYS Reflect Enterprise Manager, the NM-T1 integrates seamlessly into the Q-SYS ecosystem. It comes with table-mounting accessories, ready for immediate installation.

The NM-T1 also supports managing Acoustic Echo Cancellation (AEC) with the NM Series, ensuring optimal audio quality alongside other devices.

Bundle Includes Specifications Why we <3 it Downloads

Bundle Includes

  • Tabletop microphone

    Tabletop network PoE microphone, native to Q-SYS.

  • Power source

    Powered over Ethernet (PoE), facilitating single cable installation for both power and network connectivity.

  • Table-mounting accessories

    Comes with table-mounting accessories for easy installation.

Specifications

  • Compatibility:

    Supports Q-SYS Call Sync for synchronised status indicators across Q-SYS devices.

  • Beamforming technology:

    Advanced beamforming for clear separation of voices with four software-configurable zones providing up to 360° coverage.

  • Audio

    • Polar Pattern: Superdirective
    • Pickup Range: 3-9 ft (1-3 m)
    • Microphone Elements: 16x MEMS microphone elements
    • Frequency Response: 100 Hz - 16 kHz, +/- 3 dB
    • Sampling Rate: 16 kHz wideband / 48 kHz fullband
    • Bit Depth: 24 bit
    • Sensitivity: -36 dBFS (94 dB SPL)
    • Maximum SPL (1 kHz @ 1% THD): 118 dB SPL
    • Dynamic Range: 95 dB
    • Signal-to-Noise Ratio: 65 dB (48 kHz) / 66 dB (16 kHz)
    • Self Noise: 28 dB SPL (48 kHz) / 28 dB SPL (16 kHz)
    • Latency: 4 ms

  • Power

    • Power Requirements: Power over Ethernet (PoE), Type 1 Class 2
    • Power Consumption: <6.5 W
    • Connector Type: RJ45

  • General

    • Dimensions: 4.21 x 1.1 in (107 x 28 mm)
    • Weight: 1.5 lbs (0.68 kg)
    • Included Accessories: Mounting stem, Strain relief cap, CAT6 cable (10 ft / 3 m)

Why we <3 it

  • Aesthetic Design

    A sleek and modern design enhances the look of contemporary meeting spaces, positively impacting room aesthetics and client perceptions.

  • Scalable & adaptable

    Seamless integration with other Q-SYS products allows the NM-T1 to be part of scalable solutions that grow with client needs. Advanced features and compatibility with the Q-SYS ecosystem position the NM-T1 to adapt to future technological advancements and integration requirements.

  • Echo cancellation

    Efficiently manages acoustic echo cancellation with Q-SYS Cores, reserving AEC resources for NM Series microphones and third-party devices.

  • Touchless muting

    The proximity motion sensor enables touchless muting, allowing users to mute or unmute with a simple hand wave.

  • RGB Light Ring

    Features a programmable RGB light ring for customisable visual status indicators, including color, pattern, and speed.

  • Easy integration & management

    Offers seamless integration and comprehensive management through Q-SYS Designer Software and Q-SYS Reflect Enterprise Manager.

Downloads
